electric bike
26 x 4.0 integrate battery alloy frame rear drive hub motor fat tyre ebike
Name: 26 x 4.0 fat tyre alloy frame rear drive hub motor with Hailong downtube battery ebike
| Electric System | |
| Motor | 52V 1000W rear drive snow tire hub motor |
| Battery | 52V 20Ah frame mounted lithium battery |
| Controller | 48V 25A smart controller |
| Display | Color LCD display |
| Charger | 110-240v AC 50-60HZ, 56V 3A UL Applied |
| PAS | 1:1 PAS |
| Throttle | Thumb throttle |
| Main Components | |
| Frame | 6161 Aluminum Alloy, 26 inch. |
| Front Fork | Suspension fork. |
| Rims | Double wall, aluminum alloy, 36H*13G |
| Tires | KENDA, 26 *4.0 tire |
| Brake | Front & Rear hydraulic dsic brake,Plate: 160MM |
| Speed Gears | Shimano 8 speeds |
| Light | Front LED light |
| Rear Derailleur | Shimano 8 speeds |
| Saddle | Comfortable Saddle |
| Pedal | Aluminum pedal |
| Stem | Aluminum alloy |
| Brake Levers | Wuxing, with cut-off function |
| Crankset | Aluminum, 44T |
| Fenders | Optional |
| Rear Rack | Optional |
| Performance | |
| Max Speed | 35-45km/h |
| Travel Distance | 70km by Throttle, 80-120km by PAS |
| Loading Capacity | 120kg |
| Charging Time & Life | 4-6 Hours, >900 Cycles |
| N.W./G.W. | 28KG/32KG |
| Carton size | 160X26X80CM |
| Container Loading | 80pcs/20ft; 190pcs/40HQ |
- Motor wattage:
- 250w,500w,750w,1000w
- Motor performance:
- Gear brushless hub motor
- Motor position:
- Rear drive
- controller current:
- 14A ,18A ,22A ,25A,30A
- Display:
- LED,LCD,Color LCD
- Battery capacity:
- 10Ah lithium battery,13Ah lithium battery,20Ah
- Throttle:
- Twist throttle,Thumb throttle
- Brake:
- Disc brake,Hydraulic disc brake
- Fork suspension:
- Hydraulic suspension fork
- Light:
- F & R LED light
- Rear rack:
- Optional
- Fender:
- Optional
