TUV certificate 20 inch full suspension frame 500w fat tire electric bike

0 stars, based on 0 reviews
Price:
$0.00$485.00 / piece
Motor and battery
  • 36v 250w rear drive motor with 10.4Ah battery
  • 48v 500w rear drive motor with 13Ah battery
Quantity: - + 99 items available

Item specifics

Motor wattage:
250w,500w,750w
Motor performance:
Brushless geared hub motor
Motor position:
Rear drive
controller current:
14A,18A,22A
Display:
LED display,LCD display
Battery capacity:
13Ah LG cells battery
Throttle:
Twist throttle,Thumb throttle
Brake:
Disc brake
Fork suspension:
Hydraulic suspension
Light:
F & R LED light
Rear rack:
Alloy rear rack
Fender:
Iron fender

Name: Germany quality standard TUV certificate 20 inch full suspension frame 48v 500w bafang rear drive hub motor with 13Ah Samsung cell battery fat tire electric bike
Model:OUKA-B2
Info:(OUKA-B2) Electric bike

2017 Fat tire 20 inch full suspension folding electric bike 48V500w chinese e-bike pedelec/e bicycle

Frameset



Frame:  Aluminium alloy 6061 suspension frame 1000LB

Fork: 24" MOZO suspension fork (aluminium and steel)

Handlebar:  65-68cm U type

Grip: Velo Grip with leather or PU with color lock

Stem:  Promax MQ-527, 25.4 x 180mm, adjustable

Seat post:  Promax, aluminium alloy, suspension



Wheelset



Wheel:  36-holes double wall rim CNC, 13G stainless spokes

Tyre:  KENDA 20 x 4.0 tyre



Transmission



Chainwheel/Crank Prowheel : Topwheel 44T steel chainwheel, 170mm aluminium alloy crank

Chain:  KMC Z410ARB stainless

Rear derailleur:  Shimano SIS INDEX with protector

Freewheel:  Shimano 6-spd 14-28T

shift lever:  Shimano 6-SPD thumb shifter



Brake system



Brake levers: Tektro Aluminium alloy brake lever Artex Vigorous

Brake:  F&R Tektro disc brake



Electric system



Motor: Bafang EU: 250Watts rear hub motor(actual 350w motor)  N/A: 500W

Controller: KUNTENG EU: 15A, N/A : 22A programmable

Display:  KUNTENG LCD6 intelligent display, 9-levels

Battery: EU: 36V13Ah, N/A: 48V 13Ah lithium battery by Samsung battery cells with BMS

Charger:  2A, 110-240V applied

PAS sensor:  8 magnet PAS sensor

Throttle thumb:  type available



Else



Saddle:  Wide saddle as your requested

Front light:  LED light

Pedal:  Wellgo aluminium wider pedal

Tail light:  Rear rack with reflection

Rack aluminium alloy

Decal:  can be customized

Loading capacity: 90 Pieces/20FT 219 pieces/40HQ
